InfraMap

Read your tfstate or HCL to generate a graph specific for each provider, showing only the resources that are most important/relevant.

Cloud Providers

We support all cloud providers, but we have some (listed below) that we have specific logic that allows us to better represent information that comes from these providers.

For the other providers the resulting representation will simply be all resources present without any simplification or refinement.

For TFState generations we are limited to versions 3 and 4.

State	HCL	Grouping1	External Nodes2	IAM3
✔️	✔️	WIP	✔️	✖️ (#11)
✔️	✔️	✖️	✖️	✖️
✔️	✔️	✖️	✖️	✖️
✔️	✔️	✖️	✖️	✖️
✔️	✔️	✖️	✖️	✖️

Grouping: Group elements that belong to the same group like VPCs or regions
External Nodes: Show the ingress of the Nodes if any
IAM: Connections based on IAM (Identity Access Management)

Installation

Stable

To install the latest release of Inframap, you can pick one of this methods:

pull the latest release from the Releases page
pull the latest docker image from the Docker hub
use your Linux package manager (only AUR at the moment)

Development

You can build and install with the latest sources, you will enjoy the new features and bug fixes. It uses Go Modules (1.13+)

$ git clone https://github.com/cycloidio/inframap
$ cd inframap
$ go mod download
$ make build

Install via brew

If you're macOS user and using Homebrew, you can install via brew command:

$ brew install inframap

Usage

The inframap --help will show you the basics.

The most important subcommands are:

generate: generates the graph from STDIN or file.
prune: removes all unnecessary information from the state or HCL (not supported yet) so it can be shared without any security concerns

Example

Visualizing with dot

inframap generate state.tfstate | dot -Tpng > graph.png

or from the terminal itself with graph-easy

inframap generate state.tfstate | graph-easy

or from HCL

inframap generate config.tf | graph-easy

or HCL module

inframap generate ./my-module/ | graph-easy

using docker image (assuming that your Terraform files are in the working directory)

docker run --rm -v ${PWD}:/opt cycloid/inframap generate /opt/terraform.tfstate

or if you use docker and want to have the images generated already, the docker image has the graphviz lib installed:

docker run --rm -v ${PWD}:/opt --entrypoint "/bin/ash" inframap -c './inframap generate /opt/PATH_TO_HCL_STATE | dot -Tpng > /opt/graph.png'

and the generated image will be on $PWD/graph.png

Note: InfraMap will guess the type of the input (HCL or TFState) by validating if it's a JSON and if it fails then we fallback to HCL (except if you send a directory on args, the it'll use HCL directly), to force one specific type you can use --hcl or --tfstate flags.

How is it different to `terraform graph`

Terraform Graph outputs a dependency graph of all the resources on the tfstate/HCL. We try to go one step further, by trying to make it human-readable.

If the provider is not supported, the output will be closer to the Terraform Graph version (without displaying provider / variable nodes)

Taking https://github.com/cycloid-community-catalog/stack-magento/ as a reference this is the difference in output:

With terraform graph:

With inframap generate ./terraform/module-magento/ | dot -Tpng > inframap.png:

With inframap generate --connections=false ./terraform/module-magento/ | dot -Tpng > inframapconnections.png:

With inframap generate ./terraform/module-magento/ --raw | dot -Tpng > inframapraw.png:

How does it work?

For each provider, we support specific types of connections; we have a static list of resources that can be nodes or edges. Once we identify the edges, we try to create one unique edge from the resources they connect.

For a state file, we rely on the dependencies key (for the <0.13 we replace all depends_on for dependencies so we support them) and, for HCL we rely on interpolation to create the base graph one which we then apply specific provider logic if supported. If not supported, then basic graph is returned.

FAQ

Why is my Graph generated empty?

If a graph is returned empty, it means that we support one of the providers you are using on your HCL/TFState but we do not recognize any connection or relevant node.

To show the configuration without any InfraMap applied logic you can use the --raw flag logic and print everything that we read. If it works, it would be good to try to know why it was empty before so we can take a look at it as it could potentially be an issue on InfraMap (open an issue if you want us to take a look).

By default unconnected nodes are removed, you can use --clean=false to prevent that.

Does InfraMap support Terraform backends ?

Terraform allows users to use backends (S3, Google Cloud Storage, Swift, etc.) in order to store the terraform.state. We currently do not support graph generation from tfstate stored in such backends. As mentioned in this issue, it is possible to play around stdin/out to generate graph from Terraform backends.

backend	command
S3	`aws s3 cp s3://bucket/path/to/your/file.tfstate - \| inframap generate`
GCS	`gsutil cat gs://bucket/path/to/your/file.tfstate \| inframap generate`

A general solution is also to just use terraform state pull \| inframap generate as it'll pull the state from whichever backend is actually stored

License

Please see the MIT LICENSE file.

Changelog

All notable changes to this project will be documented in this file.

The format is based on Keep a Changelog, and this project adheres to Semantic Versioning.
